应用

Application

皮带秤

Belt scale

型号

Model

UB25

量程

Capacity                                               Kg

5、10、20、30、50、100、200、300、500

输出灵敏度

Output sensitivity                               MV/V

20.±0.004

非线性

Nonlinearity                                         %FS

0.02

重复性

Repeatability                                       %FS

0.01

迟滞

Hysteresis                                           %FS

0.02

蠕变

Creep                                              %FS 30min

0.02

温度灵敏度漂移

Temperature effect on sensitivity     %FS℃

0.0016

温度零点漂移

Temperature effect on zero              %FS℃

0.0026

零点平衡

Zero balance                                       %FS

±1.0

输入阻抗

 Input resistance                                   Ω

365±5

输出阻抗

Output resistance                                 Ω

350±3

绝缘电阻

Insulation resistance                          MΩ

5000

激励电压

Recommended excitation voltage        V

10

大激励电压

Maximum excitation voltage                V

15

温度补偿范围

Compensated temperature range        ℃

-10-+55

工作温度范围

Operating temperature range              ℃

-35-+70

安全载能力

Safe overload                                      %FS

150

极限载范围

Ultimate overload                               %FS

300

防护等级

Protection class

IP67

传感器材料

Load cell material

合金铝Alloy AI

接线电缆

Connecting cable

3m

接线方式

Method of connecting wire

6线wire
